序

本文主要研究一下Java11的HttpClient的基本使用。

变化

• 从java9的jdk.incubator.httpclient模块迁移到java.net.http模块，包名由jdk.incubator.http改为java.net.http
• 原来的诸如HttpResponse.BodyHandler.asString()方法变更为HttpResponse.BodyHandlers.ofString()，变化一为BodyHandler改为BodyHandlers，变化二为asXXX()之类的方法改为ofXXX()，由as改为of

实例

设置超时时间

@Test    public void testTimeout() throws IOException, InterruptedException {        //1.set connect timeout        HttpClient client = HttpClient.newBuilder()                .connectTimeout(Duration.ofMillis(5000))                .followRedirects(HttpClient.Redirect.NORMAL)                .build();        //2.set read timeout        HttpRequest request = HttpRequest.newBuilder()                .uri(URI.create("http://openjdk.java.net/"))                .timeout(Duration.ofMillis(5009))                .build();        HttpResponse

      response =                client.send(request, HttpResponse.BodyHandlers.ofString());        System.out.println(response.body());    }


• HttpConnectTimeoutException实例

Caused by: java.net.http.HttpConnectTimeoutException: HTTP connect timed out    at java.net.http/jdk.internal.net.http.ResponseTimerEvent.handle(ResponseTimerEvent.java:68)    at java.net.http/jdk.internal.net.http.HttpClientImpl.purgeTimeoutsAndReturnNextDeadline(HttpClientImpl.java:1248)    at java.net.http/jdk.internal.net.http.HttpClientImpl$SelectorManager.run(HttpClientImpl.java:877)Caused by: java.net.ConnectException: HTTP connect timed out    at java.net.http/jdk.internal.net.http.ResponseTimerEvent.handle(ResponseTimerEvent.java:69)    ... 2 more

• HttpTimeoutException实例

java.net.http.HttpTimeoutException: request timed out    at java.net.http/jdk.internal.net.http.HttpClientImpl.send(HttpClientImpl.java:559)    at java.net.http/jdk.internal.net.http.HttpClientFacade.send(HttpClientFacade.java:119)    at com.example.HttpClientTest.testTimeout(HttpClientTest.java:40)

设置authenticator

@Test    public void testBasicAuth() throws IOException, InterruptedException {        HttpClient client = HttpClient.newBuilder()                .connectTimeout(Duration.ofMillis(5000))                .authenticator(new Authenticator() {                    @Override                    protected PasswordAuthentication getPasswordAuthentication() {                        return new PasswordAuthentication("admin","password".toCharArray());                    }                })                .build();        HttpRequest request = HttpRequest.newBuilder()                .uri(URI.create("http://localhost:8080/json/info"))                .timeout(Duration.ofMillis(5009))                .build();        HttpResponse

      response =                client.send(request, HttpResponse.BodyHandlers.ofString());        System.out.println(response.statusCode());        System.out.println(response.body());    }


• authenticator可以用来设置HTTP authentication，比如Basic authentication
• 虽然Basic authentication也可以自己设置header，不过通过authenticator省得自己去构造header

设置header

@Test    public void testCookies() throws IOException, InterruptedException {        HttpClient client = HttpClient.newBuilder()                .connectTimeout(Duration.ofMillis(5000))                .build();        HttpRequest request = HttpRequest.newBuilder()                .uri(URI.create("http://localhost:8080/json/cookie"))                .header("Cookie","JSESSIONID=4f994730-32d7-4e22-a18b-25667ddeb636; userId=java11")                .timeout(Duration.ofMillis(5009))                .build();        HttpResponse

      response =                client.send(request, HttpResponse.BodyHandlers.ofString());        System.out.println(response.statusCode());        System.out.println(response.body());    }


• 通过request可以自己设置header

GET

• 同步

@Test    public void testSyncGet() throws IOException, InterruptedException {        HttpClient client = HttpClient.newHttpClient();        HttpRequest request = HttpRequest.newBuilder()                .uri(URI.create("https://www.baidu.com"))                .build();        HttpResponse

      response =                client.send(request, HttpResponse.BodyHandlers.ofString());        System.out.println(response.body());    }


• 异步

@Test    public void testAsyncGet() throws ExecutionException, InterruptedException {        HttpClient client = HttpClient.newHttpClient();        HttpRequest request = HttpRequest.newBuilder()                .uri(URI.create("https://www.baidu.com"))                .build();        CompletableFuture

      result = client.sendAsync(request, HttpResponse.BodyHandlers.ofString())                .thenApply(HttpResponse::body);        System.out.println(result.get());    }


POST表单

@Test    public void testPostForm() throws IOException, InterruptedException {        HttpClient client = HttpClient.newBuilder().build();        HttpRequest request = HttpRequest.newBuilder()                .uri(URI.create("http://www.w3school.com.cn/demo/demo_form.asp"))                .header("Content-Type","application/x-www-form-urlencoded")                .POST(HttpRequest.BodyPublishers.ofString("name1=value1&name2=value2"))                .build();        HttpResponse

      response = client.send(request, HttpResponse.BodyHandlers.ofString());        System.out.println(response.statusCode());    }


• header指定内容是表单类型，然后通过BodyPublishers.ofString传递表单数据，需要自己构建表单参数

POST JSON

@Test    public void testPostJsonGetJson() throws ExecutionException, InterruptedException, JsonProcessingException {        ObjectMapper objectMapper = new ObjectMapper();        StockDto dto = new StockDto();        dto.setName("hj");        dto.setSymbol("hj");        dto.setType(StockDto.StockType.SH);        String requestBody = objectMapper                .writerWithDefaultPrettyPrinter()                .writeValueAsString(dto);        HttpRequest request = HttpRequest.newBuilder(URI.create("http://localhost:8080/json/demo"))                .header("Content-Type", "application/json")                .POST(HttpRequest.BodyPublishers.ofString(requestBody))                .build();        CompletableFuture

      result = HttpClient.newHttpClient()                .sendAsync(request, HttpResponse.BodyHandlers.ofString())                .thenApply(HttpResponse::body)                .thenApply(body -> {                    try {                        return objectMapper.readValue(body,StockDto.class);                    } catch (IOException e) {                        return new StockDto();                    }                });        System.out.println(result.get());    }


• post json的话，body自己json化为string，然后header指定是json格式

文件上传

@Test    public void testUploadFile() throws IOException, InterruptedException, URISyntaxException {        HttpClient client = HttpClient.newHttpClient();        Path path = Path.of(getClass().getClassLoader().getResource("body.txt").toURI());        File file = path.toFile();        String multipartFormDataBoundary = "Java11HttpClientFormBoundary";        org.apache.http.HttpEntity multipartEntity = MultipartEntityBuilder.create()                .addPart("file", new FileBody(file, ContentType.DEFAULT_BINARY))                .setBoundary(multipartFormDataBoundary) //要设置，否则阻塞                .build();        HttpRequest request = HttpRequest.newBuilder()                .uri(URI.create("http://localhost:8080/file/upload"))                .header("Content-Type", "multipart/form-data; boundary=" + multipartFormDataBoundary)                .POST(HttpRequest.BodyPublishers.ofInputStream(() -> {                    try {                        return multipartEntity.getContent();                    } catch (IOException e) {                        e.printStackTrace();                        throw new RuntimeException(e);                    }                }))                .build();        HttpResponse

      response =                client.send(request, HttpResponse.BodyHandlers.ofString());        System.out.println(response.body());    }


• 官方的HttpClient并没有提供类似WebClient那种现成的BodyInserters.fromMultipartData方法，因此这里需要自己转换
• 这里使用org.apache.httpcomponents(httpclient及httpmime)的MultipartEntityBuilder构建multipartEntity，最后通过HttpRequest.BodyPublishers.ofInputStream来传递内容
• 这里header要指定Content-Type值为multipart/form-data以及boundary的值，否则服务端可能无法解析

文件下载

@Test    public void testAsyncDownload() throws ExecutionException, InterruptedException {        HttpClient client = HttpClient.newHttpClient();        HttpRequest request = HttpRequest.newBuilder()                .uri(URI.create("http://localhost:8080/file/download"))                .build();        CompletableFuture

      result = client.sendAsync(request, HttpResponse.BodyHandlers.ofFile(Paths.get("/tmp/body.txt")))                .thenApply(HttpResponse::body);        System.out.println(result.get());    }


• 使用HttpResponse.BodyHandlers.ofFile来接收文件

并发请求

@Test    public void testConcurrentRequests(){        HttpClient client = HttpClient.newHttpClient();        List

      urls = List.of("http://www.baidu.com","http://www.alibaba.com/","http://www.tencent.com");        List

       requests = urls.stream()                .map(url -> HttpRequest.newBuilder(URI.create(url)))                .map(reqBuilder -> reqBuilder.build())                .collect(Collectors.toList());        List



         >> futures = requests.stream()                .map(request -> client.sendAsync(request, HttpResponse.BodyHandlers.ofString()))                .collect(Collectors.toList());        futures.stream()                .forEach(e -> e.whenComplete((resp,err) -> {                    if(err != null){                        err.printStackTrace();                    }else{                        System.out.println(resp.body());                        System.out.println(resp.statusCode());                    }                }));        CompletableFuture.allOf(futures                .toArray(CompletableFuture
         []::new))                .join();    }






• sendAsync方法返回的是CompletableFuture，可以方便地进行转换、组合等操作
• 这里使用CompletableFuture.allOf组合在一起，最后调用join等待所有future完成

错误处理

@Test    public void testHandleException() throws ExecutionException, InterruptedException {        HttpClient client = HttpClient.newBuilder()                .connectTimeout(Duration.ofMillis(5000))                .build();        HttpRequest request = HttpRequest.newBuilder()                .uri(URI.create("https://twitter.com"))                .build();        CompletableFuture

      result = client.sendAsync(request, HttpResponse.BodyHandlers.ofString())//                .whenComplete((resp,err) -> {//                    if(err != null){//                        err.printStackTrace();//                    }else{//                        System.out.println(resp.body());//                        System.out.println(resp.statusCode());//                    }//                })                .thenApply(HttpResponse::body)                .exceptionally(err -> {                    err.printStackTrace();                    return "fallback";                });        System.out.println(result.get());    }


• HttpClient异步请求返回的是CompletableFuture<HttpResponse<T>>，其自带exceptionally方法可以用来做fallback处理
• 另外值得注意的是HttpClient不像WebClient那样，它没有对4xx或5xx的状态码抛出异常，需要自己根据情况来处理，手动检测状态码抛出异常或者返回其他内容

HTTP2

@Test    public void testHttp2() throws URISyntaxException {        HttpClient.newBuilder()                .followRedirects(HttpClient.Redirect.NEVER)                .version(HttpClient.Version.HTTP_2)                .build()                .sendAsync(HttpRequest.newBuilder()                                .uri(new URI("https://http2.akamai.com/demo"))                                .GET()                                .build(),                        HttpResponse.BodyHandlers.ofString())                .whenComplete((resp,t) -> {                    if(t != null){                        t.printStackTrace();                    }else{                        System.out.println(resp.version());                        System.out.println(resp.statusCode());                    }                }).join();    }

• 执行之后可以看到返回的response的version为HTTP_2

WebSocket

@Test    public void testWebSocket() throws InterruptedException {        HttpClient client = HttpClient.newHttpClient();        WebSocket webSocket = client.newWebSocketBuilder()                .buildAsync(URI.create("ws://localhost:8080/echo"), new WebSocket.Listener() {                    @Override                    public CompletionStage
     onText(WebSocket webSocket, CharSequence data, boolean last) {                        // request one more                        webSocket.request(1);                        // Print the message when it's available                        return CompletableFuture.completedFuture(data)                                .thenAccept(System.out::println);                    }                }).join();        webSocket.sendText("hello ", false);        webSocket.sendText("world ",true);        TimeUnit.SECONDS.sleep(10);        webSocket.sendClose(WebSocket.NORMAL_CLOSURE, "ok").join();    }

• HttpClient支持HTTP2，也包含了WebSocket，通过newWebSocketBuilder去构造WebSocket
• 传入listener进行接收消息，要发消息的话，使用WebSocket来发送，关闭使用sendClose方法

reactive streams

HttpClient本身就是reactive的，支持reactive streams，这里举ResponseSubscribers.ByteArraySubscriber的源码看看：

java.net.http/jdk/internal/net/http/ResponseSubscribers.java

public static class ByteArraySubscriber

      implements BodySubscriber

       {        private final Function

        finisher;        private final CompletableFuture

         result = new MinimalFuture<>();        private final List

          received = new ArrayList<>();        private volatile Flow.Subscription subscription;        public ByteArraySubscriber(Function

           finisher) { this.finisher = finisher; } @Override public void onSubscribe(Flow.Subscription subscription) { if (this.subscription != null) { subscription.cancel(); return; } this.subscription = subscription; // We can handle whatever you've got subscription.request(Long.MAX_VALUE); } @Override public void onNext(List

            items) { // incoming buffers are allocated by http client internally, // and won't be used anywhere except this place. // So it's free simply to store them for further processing. assert Utils.hasRemaining(items); received.addAll(items); } @Override public void onError(Throwable throwable) { received.clear(); result.completeExceptionally(throwable); } static private byte[] join(List

             bytes) { int size = Utils.remaining(bytes, Integer.MAX_VALUE); byte[] res = new byte[size]; int from = 0; for (ByteBuffer b : bytes) { int l = b.remaining(); b.get(res, from, l); from += l; } return res; } @Override public void onComplete() { try { result.complete(finisher.apply(join(received))); received.clear(); } catch (IllegalArgumentException e) { result.completeExceptionally(e); } } @Override public CompletionStage

              getBody() { return result; } }










• BodySubscriber接口继承了Flow.Subscriber<List<ByteBuffer>>接口
• 这里的Subscription来自Flow类，该类是java9引入的，里头包含了支持Reactive Streams的实现

小结

HttpClient在Java11从incubator变为正式版，相对于传统的HttpUrlConnection其提升可不是一点半点，不仅支持异步，也支持reactive streams，同时也支持了HTTP2以及WebSocket，非常值得大家使用。
